MTPS18B Fine Corn Peeling Machine

Product properties
  • Summary:
    Capacity:4-6t/h
    Application:MTPS18B Fine corn peeling machine is newly improved through wide market investigation along with advantages and experiences from home and abroad. It is mainly used in corn, beans and coarse cereal processing plant for hulling and polishing.

Brief Introduction

The MTPS18B corn peeling machine adopts dry peeling and is suitable for peeling and embryo removal in newly built corn processing production lines; Upgrading of peeling and dehulling equipment for old corn processing production lines; Equipment for peeling and kernel making in small-scale corn processing plants; Equipment for peeling and removing mold from feed processing production lines.

Function and Feature

1.High yield of finished products
Using special sand rollers and sieve plates, it has a longer lifespan, efficient peeling, blackening, and embryo removal, low crushing rate, and high yield of finished products;
2.Easy to use
Adopting locking and self-aligning bearings, non boring machine frame, spindle fan, and split type screen frame for easy installation and disassembly;
3.High yield and energy-saving
High yield, efficient, energy-saving, and occupying a small area, it is a specialized machine for corn processing production lines and corn feed processing industries;
4.Durable
The diamond sand roller can run continuously for more than 8000 hours, and the diamond sandblasting screen plate can run continuously for more than 6000 hours, with durability and cost savings.

Working Principle

The corn goes in the propelling chamber through charging regulation device where the spiral pusher conveys them to emery roll whose sharp appearance cuts the bran at a speed, making the beans particles rub against the sieve plate, so as to dehull the materials. The outlet is equipped with air suction inlet to further cool down the corn and clean the finished product for the second time.

Finished Product

Finished Product of MTPS18B Fine Corn Peeling Machine

Technical Parameter

Type Emery Roll
Diameter(mm)
Emery Roll Length(mm) Spindle Speed(r/min) Capacity(t/h) Power(kw) Air Volume(m³/h) Dimension(mm)
MTPS-18Y/A Φ180 660 1300 1-1.5 22   1370×700×1900
MTPS-18Y/B Φ180 660 1300 1-1.5 22 1500-1800 1410×1220×2030
MTPS-25Y/A Φ240 660 1050 2.5-3.5 30   1515×660×2100
MTPS-25Y/B Φ240 660 1050 2.5-3.5 30 1800-2100 1515×1220×2100
MTPS-30Y/A Φ300 800 850 4-6 37-45   1690×710×2180

After-sale Service

1.Timely provide Party A with all the technical materials and drawings as the contract; compile and supplement operation manual according to the final commissioning results.
2.Party B offers on-site training service according to progress of the project, installing, trying operation and production of the whole line as it is required on the technical materials and drawings.
3.Party B gives training of installation, commissioning, use and maintenance to staff of Party A under their arrangement.
4.Instruct operators and maintenance staff.
5.Increase pre-sale, in-sale and after-sale service, implementing super pre-sale, full process and life long service through manufacturing, installation, commissioning and production.
6.During warranty period, Party B will provide an answer or staff within 4 hours once receiving feedbacks about quality of the products. Party B will arrive at the site as soon as possible, change and maintain the spare parts for free. The service will never stop until the clients are satisfied.
7.Beyond warranty period, Party B is on call to provide paid service for improvement of technology, maintenance of the machine or offer of the spare parts.
